Description
Product Overview
The Thincol XY-axis precision manual fine-tuning sliding table is engineered for high-accuracy industrial and scientific applications. This dual-axis micrometer displacement platform features a robust aluminum alloy construction with black anodized finish for enhanced durability and corrosion resistance. With a compact sliding table size of 100x100mm and overall dimensions of 205x212x45mm, it delivers precise movement through cross roller linear guides. The platform offers a ±12.5mm stroke range while maintaining impressive specifications including 50μm parallelism, 20μm moving parallelism, and 3μm straightness. Designed to handle loads up to 140N, this sliding table ensures consistent performance in demanding environments where micron-level precision is critical.
Usage
This precision sliding table is ideal for laboratory testing environments requiring exact positioning and repeatable measurements. It serves mechanical equipment applications where precise movement and registration adjustment are essential, particularly in optical waveguide alignment, fiber coupling systems, and capacitive touch screen production equipment. The platform is commonly used by research institutions, manufacturing facilities, and engineering teams working with high-precision assembly processes. Its micrometer-level adjustment capability makes it suitable for calibration procedures, quality control stations, and prototype development where sub-millimeter accuracy is mandatory.
Why Choose Us
Thincol sliding tables stand out through their commitment to precision engineering and quality manufacturing. The cross roller guide system provides superior stability and smooth movement compared to conventional linear bearings, ensuring minimal backlash and consistent performance over extended use. Each unit undergoes rigorous quality checks to verify parallelism, straightness, and load capacity specifications. The anodized aluminum construction not only enhances durability but also maintains dimensional stability across temperature variations. With a proven track record in industrial applications and positive customer feedback, Thincol delivers reliable precision tools that meet the demanding requirements of professional users.
Key Features
- Dual-axis micrometer adjustment for precise XY positioning control
- Cross roller guide system ensuring smooth, stable movement with minimal friction
- Aluminum alloy construction with black anodized finish for durability and corrosion resistance
- ±12.5mm stroke range with micrometer-level positioning accuracy
- 140N load capacity suitable for various industrial and laboratory applications
FAQ
What is the maximum load capacity of this sliding table?
The sliding table can support loads up to 140N while maintaining its precision specifications and smooth operation.
How precise are the micrometer adjustments?
The platform provides micrometer-level adjustments with 3μm straightness and 20μm moving parallelism for high-precision positioning requirements.
What applications is this sliding table suitable for?
It is designed for laboratory precision testing, mechanical equipment positioning, fiber coupling, optical alignment, and various industrial production systems requiring exact movement control.
What type of guide system does it use?
The table utilizes cross roller linear guides which offer superior stability, minimal backlash, and smooth movement compared to standard linear bearing systems.
What are the overall dimensions of the unit?
The product measures 205x212x45mm with a sliding table surface of 100x100mm, making it compact yet capable for various precision applications.
